CNC Lathe-D

CK611 sequence machine tool is a massive horizontal flat bed CNC lathe, and a full digital AC servo system. The main power D, L, B, H type is automatic two-speed stepless transmission, the essential motor is AC spindle motor, E, N type is manual four-speed stepless variable speed, the predominant motor is DC motor, and two linkage control shafts. The Z axis and X axis of the machine device with a center distance of 1-6M use ball screw pair plus AC servo motor to realize longitudinal and lateral movement; The Z axis of the desktop tool with a center distance of greater than 7M adopts rack and pinion plus grating ruler, and the X axis adopts ball screw pair plus AC servo motor to achieve longitudinal and lateral movement, which has good positioning and repeated positioning accuracy.

The product is developed from light to heavy-duty, with a sliveting diameter of more than 1000mm, a load-bearing capability of 6t to 80t, a maximum processing length of 20m, and a most swing diameter of 3.5m.

CK61100D CNC lathe bears 6t, CK61125L CNC lathe bears 10t, CK61200W series bears 20t, CKZ series bears 30t, CKG collection CNC heavy truck bears 40t, 60t, 80t.
